1995 Kawasaki Ninja® 250R Radiator Diagram

← All diagrams

Find the part on the Radiator diagram for your 1995 Kawasaki Ninja® 250R, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1995 Kawasaki Ninja® 250R Radiator Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

130

BOLT-FLANGED,6X10

130C0610

1
Out of stock

11009

1

$1.25

In stock

11012

CAP

11012-1084

1

$1.31

In stock

14024

COVER,THERMOSTAT

14024-1232

1
Out of stock

14037

SCREEN

14037-1078

1

$68.78

In stock

14075

CAP-ASSY,RADIATOR

14075-1061

1

$151.97

In stock

16160

BODY,THERMOSTAT

16160-1110

1

$41.29

In stock

21126

1

$3.75

In stock

27010

SWITCH,THERMOSTAT

27010-1304

1

$91.29

In stock

32102

1

$25.24

In stock

32102A

PIPE

32102-1531

1
Out of stock

32150

PIPE

32150-1143

1
Out of stock

39060

RADIATOR

39060-1087

1

$631.30

In stock

39062

1

$38.54

In stock

39062A

HOSE-COOLING

39062-1028

1
Out of stock

39062B

1

$20.61

In stock

39062C

1

$42.13

In stock

39062D

1

$28.79

In stock

39062E

1

$16.54

In stock

39062F

1

$11.27

In stock

43078

RESERVOIR

43078-1070

1

$46.47

In stock

49044

PUMP-WATER

49044-1064

1

$311.04

In stock

49054

THERMOSTAT

49054-1058

1

$62.23

In stock

49085

CAP-ASSY-PRESSURE

49085-1066

1

$33.98

In stock

59502

FAN-ASSY

59502-1066

1

$587.78

In stock

92001

BOLT,W/WASHER,6X12

92001-1516

1

$4.42

In stock

92005

FITTING,CYLINDER

92005-1145

1
Out of stock

92015

NUT

92015-1487

1

$3.80

In stock

92022

WASHER,6MM

92022-1976

1
Out of stock

92037

CLAMP,TUBE

92037-147

1

$5.84

In stock

92055

RING-O,27.7X2.4

92055-091

1

$4.93

In stock

92055A

RING-O

92055-1432

1

$9.42

In stock

92059

TUBE,FAN SWITCH

92059-1979

1

$2.31

In stock

92066

PLUG,SENSOR WATER

92066-1183

1

$60.95

In stock

92075

DAMPER

92075-1665

1

$6.83

In stock

92143

COLLAR

92143-1063

1
Out of stock

92150

BOLT,6X12

92150-1186

1

$2.92

In stock

92150A

BOLT

92150-1562

1

$4.08

In stock

92170

CLAMP,COOLING HOSE

92170-1033

1

$11.99

In stock

92170A

CLAMP,HOSE,32MM

92170-1286

1
Out of stock

130A

BOLT-FLANGED,6X25

130J0625

1
Out of stock

130B

BOLT-FLANGED,6X35

130J0635

1
Out of stock

132

BOLT-FLANGED-SMALL

132G0612

1
Out of stock

132A

BOLT-FLANGED-SMALL

132G0625

1
Out of stock

132B

BOLT-FLANGED-SMALL,6X12

132J0612

1
Out of stock

132C

BOLT-FLANGED-SMALL,6X16

132J0616

1
Out of stock

132D

BOLT-FLANGED-SMALL,6X30

132J0630

1
Out of stock

186

BOLT-UPSET-WP,6X16

186C0616

1
Out of stock

670

O RING,16MM

670B2016

1

$1.20

In stock

670A

O RING,18MM

670B2018

1

$1.25

In stock

671

O RING

671D2535

1

$4.93

In stock
