2023 Kawasaki KLR®650 Adventure Headlight Diagram

← All diagrams

Find the part on the Headlight diagram for your 2023 Kawasaki KLR®650 Adventure, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2023 Kawasaki KLR®650 Adventure Headlight Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11057

BRACKET,HEAD LAMP

11057-7884

1
Out of stock

23004

LAMP-HEAD,LED

23004-0414

1
Out of stock

23016

LAMP-ASSY,LED,FOG,PIAA

23016-0599

1
Out of stock

26031

HARNESS,FOG LAMP

26031-3860

1
Out of stock

27010

SWITCH,FOG LAMP

27010-0968

1
Out of stock

35063

STAY,LH

35063-1537

1
Out of stock

35063A

STAY,RH

35063-1538

1
Out of stock

39137

STAY-COMP,MAIN

39137-0713

1
Out of stock

55020

GUARD,OUTER

55020-1825

1
Out of stock

55020A

GUARD,INNER

55020-1826

1
Out of stock

56054

MARK,FOG LAMP,KAWASAKI

56054-1695

1
Out of stock

92151

BOLT,SOCKET,6X25

92151-1611

1
Out of stock

92152

COLLAR,6.5X20X12

92152-2262

1
Out of stock

92152A

COLLAR,6.3X20X15.1

92152-2322

1
Out of stock

92153

BOLT,SOCKET,6X16

92153-1526

1
Out of stock

92154

BOLT,SOCKET,5X12

92154-0917

1
Out of stock

92154A

BOLT,FLANGED,8X12

92154-4252

1
Out of stock

92160

DAMPER,10X20X12

92160-1167

1
Out of stock

92160A

DAMPER

92160-1613

1
Out of stock

92161

DAMPER,8X14X8.9

92161-1666

1

$1.32

In stock

92171

CLAMP

92171-1539

1
Out of stock

92172

SCREW,TAPPING,4X12

92172-0233

1
Out of stock

92172A

SCREW,5X10

92172-0864

1
Out of stock

130

BOLT-FLANGED,6X16

130BA0616

1

$1.12

In stock

130A

BOLT-FLANGED,6X25

130BB0625

1

$1.92

In stock

411

WASHER-PLAIN,5MM

411AB0500

1
Out of stock
