1993 Kawasaki Ninja® ZX™-11 Battery Case Diagram

← All diagrams

Find the part on the Battery Case diagram for your 1993 Kawasaki Ninja® ZX™-11, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1993 Kawasaki Ninja® ZX™-11 Battery Case Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11012

CAP

11012-1460

1
Out of stock

11012A

CAP

11012-1657

1
Out of stock

11046

BRACKET,FUEL PUMP

11046-1262

1
Out of stock

11046A

BRACKET,MUFFLER STAY

11046-1722

1
Out of stock

11046B

BRACKET,RADIATOR,LH

11046-1890

1
Out of stock

11046C

BRACKET,RADIATOR,RH

11046-1891

1
Out of stock

11046D

BRACKET,TAIL GRIP

11046-1934

1
Out of stock

11046E

BRACKET,OIL COOLER

11046-1936

1
Out of stock

11046F

BRACKET,RETURN PUMP

11046-1952

1
Out of stock

11046G

BRACKET,RR FENDER,FR

11046-1975

1
Out of stock

14069

BREATHER

14069-1054

1
Out of stock

32109

GRIP-FRAME

32109-1198

1
Out of stock

35011B

STAY,STEP HOLDER,RH,BLACK

35011-1417-10

1
Out of stock

35011E

STAY,STEP HOLDER,LH,BLACK

35011-1520-10

1
Out of stock

35011H

STAY,RR,LH,BLACK

35011-1521-10

1
Out of stock

35011K

STAY,RR,RH,BLACK

35011-1522-10

1
Out of stock

46075

GRIP,TAIL,EBONY

46075-1091-H8

1

$230.42

In stock

53045

HOOK-ASSY,ROPE

53045-1057

1

$41.39

In stock

92002

BOLT,SOCKET,8X22

92002-1334

1
Out of stock

92002A

BOLT,SOCKET,8X20

92002-1493

1
Out of stock

92037

CLAMP,TUBE

92037-147

1
Out of stock

92037A

CLAMP,HOSE

92037-1875

1
Out of stock

92072

BAND,L=90

92072-045

1
Out of stock

92072A

BAND,L=150

92072-1188

1
Out of stock

92160

DAMPER,ROPE HOOK

92160-1042

1
Out of stock

130

BOLT-FLANGED

130J0610

1
Out of stock

130A

BOLT-FLANGED,6X14,BLACK

130J0614

1
Out of stock

130B

BOLT-FLANGED,6X16,BLACK

130J0616

1
Out of stock

130C

BOLT-FLANGED,8X12

130J0812

1
Out of stock

130D

BOLT-FLANGED,8X20

130J0820

1
Out of stock

130E

BOLT-FLANGED,8X25,BLACK

130J0825

1
Out of stock

221

SCREW-CSK-CROS,6X25

221E0625

1
Out of stock

702

TUBE-RUBBER,7X10X380

702A07380

1
Out of stock
