Find the part on the Fender diagram for your 1981 Yamaha XT250H, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1981 Yamaha XT250H Fender Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

FENDER, FRONT

3C5-21511-10-00

1
Out of stock

2

COLLAR (8G8)

90387-06681-00

1

$6.62

In stock

3

COLLAR

90387-06117-00

1

$7.14

In stock

4

BOLT, WITH WASHER

90119-06147-00

1

$0.71

In stock

5

FENDER, FRONT 2

3C5-21556-00-00

1

$19.00

In stock

6

COLLAR (8G8)

90387-06681-00

1

$6.62

In stock

7

BOLT, WITH WASHER

90119-06147-00

1

$0.71

In stock

8

GROMMET

90480-13014-00

1

$6.85

In stock

9

FENDER, REAR

3C5-21611-50-00

1
Out of stock

10

BOLT, FLANGE

95022-06012-00

1

$3.00

In stock

11

COLLAR

90387-06107-00

1

$7.05

In stock

12

COVER, REAR FENDER 1

3C5-2163A-00-00

—
Out of stock

13

PLUG

90338-07018-00

1

$5.82

In stock

14

GUARD, FLAP

5XT-21642-02-00

—
Out of stock

15

BOLT, FLANGE

95817-06016-00

1

$1.49

In stock

16

WASHER, PLATE

90201-06055-00

1

$2.92

In stock

17

EMBLEM

3C5-2411B-00-00

—

$6.51

In stock

18

COLLAR(4JW)

90387-0602Y-00

—
Out of stock

19

BOLT, HEXAGON

97017-06030-00

—

$3.00

In stock

20

WASHER, PLAIN (646)

92990-06600-00

—

$2.48

In stock

21

DAMPER

4XV-83513-00-00

—

$6.42

In stock

22

DAMPER

3C5-84527-10-00

—
Out of stock

23

BRACKET 3

3C5-2161A-00-00

—
Out of stock

24

PROTECTOR

3C5-21652-00-00

—
Out of stock

25

COLLAR

90387-06M21-00

1

$8.45

In stock

26

BOLT, HEXAGON

97017-06030-00

—

$3.00

In stock

27

DAMPER 1

4D9-28415-00-00

—

$4.74

In stock

28

BRACKET, LICENCE

3C5-84551-00-00

—
Out of stock

29

COLLAR, 2

3C5-21634-00-00

—
Out of stock

30

BOLT, FLANGE

90105-06170-00

—

$4.23

In stock

31

CLAMP(4GY)

90464-05188-00

—
Out of stock

32

CLAMP

5Y9-12491-00-00

—

$6.38

In stock
