Description

Price

1

CYLINDER ASSY, REAR MASTER | Includes Item(s) 2 - 9 This part replaces 69604-37F20.

69604-37F30

$331.52

2

.PISTON/CUP SET This part replaces 69600-04820.

69600-04821

$29.55

3

.BOOT

69691-00A00

$5.00

4

YOKE

69692-13E00

$18.80

5

ROD, PUSH

69670-40A00

$28.90

6

NUT

69693-05A00

$1.86

7

CAP

69669-37F20

$44.55

8

DIAPHRAGM

69667-37F20

$18.25

9

SCREW

69689-37F20

$5.10

10

SCREW(6X16) This part replaces 09139-06067.

09139-06237

$2.35

11

NO DESCRIPTION AVAILABLE This part replaces 69480-36F10.

69480-36F11

Unavailable

12

UNION This part replaces 09360-10042.

09360-10062

$5.81

13

WASHER (10X15X1.5)

09161-10009

$1.83

14

GUIDE RR BRAKE (HOLE 1-5.5) This part replaces 61196-27C30.

61196-27C50

$5.65

15

SCREW This part replaces 02142-05103.

02142-0510B

$1.77

16

PIN

09200-08048

$2.80

17

WASHER This part replaces 09160-08119.

09160-08090

$2.38

18

.COTTER PIN This part replaces 04111-20158.

04111-2015A

$1.22

Suzuki RM250 (2006) REAR MASTER CYLINDER (MODEL K4) Diagram
