Find the part on the Battery Case diagram for your 1995 Kawasaki ZR1100 Zephyr, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1995 Kawasaki ZR1100 Zephyr Battery Case Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11012

CAP,SWING ARM BRACKET

11012-1459

1
Out of stock

11012A

CAP,BUNGEE CORD HOOK

11012-1589

1
Out of stock

11012B

CAP,CROSS PIPE,C.GRAY

11012-1717-EZ

1
Out of stock

11047

BRACKET,GRABRAIL,LH

11047-1604

1
Out of stock

11047A

BRACKET,GRABRAIL,RH

11047-1605

1
Out of stock

11047B

BRACKET,DUCT

11047-1625

1
Out of stock

11047C

BRACKET,IGNITER

11047-1735

1
Out of stock

14069

BREATHER

14069-1061

1

$16.69

In stock

14073

DUCT,LH

14073-1528

1

$56.36

In stock

14073A

DUCT,RH

14073-1529

1

$56.67

In stock

14090

COVER,BATTERY

14090-1170

1

$17.14

In stock

14090A

COVER,REAR FENDER,UPP

14090-1181

1
Out of stock

27012

HOOK,BUNGEE CORD

27012-1459

1
Out of stock

32109

GRIP-FRAME

32109-1219

1
Out of stock

34003

HOLDER-STEP

34003-1327

1
Out of stock

35011

STAY,MUFFLER,LH,C.GRAY

35011-1602-EZ

1
Out of stock

35011A

STAY,MUFFLER,RH,C.GRAY

35011-1603-EZ

1
Out of stock

35011B

STAY,SWING ARM PANEL,LH,C.GRAY

35011-1604-EZ

1
Out of stock

35011C

STAY,SWING ARM PANEL,RH,C.GRAY

35011-1605-EZ

1
Out of stock

46075

GRIP,GRABRAIL,L.V.RED

46075-1098-P5

1
Out of stock

55020

GUARD,CHAIN

55020-1422

1
Out of stock

92001

BOLT,SIDE STAND LEVER

92001-1955

1
Out of stock

92009

SCREW,6X18,BLACK

92009-1181

1
Out of stock

92009A

SCREW,6X14

92009-1288

1
Out of stock

92037

CLAMP,TUBE

92037-147

1
Out of stock

92075

DAMPER

92075-1947

1
Out of stock

92143

COLLAR

92143-1057

1
Out of stock

92150

BOLT,SOCKET,10X25

92150-1268

1
Out of stock

92150B

BOLT,FLANGED,8X30

92150-1603

1
Out of stock

92150C

BOLT,SOCKET,10X25

92150-1747

1
Out of stock

92150D

BOLT,SOCKET,8X20

92150-1760

1
Out of stock

92160

DAMPER,4.5X11X20

92160-1074

1
Out of stock

92160A

DAMPER,GRABRAIL,LH

92160-1341

1
Out of stock

92160B

DAMPER,GRABRAIL,RH

92160-1342

1
Out of stock

92170

CLAMP,HOSE

92170-1320

1

$9.42

In stock

130

BOLT-FLANGED,6X10

130G0610

1
Out of stock

130A

BOLT-FLANGED

130J0610

1
Out of stock

130B

BOLT-FLANGED,8X14

130J0814

1
Out of stock

220

SCREW-PAN-CROS,5X10

220C0510

1
Out of stock

702

TUBE-RUBBER,7X10X280

702A07280

1
Out of stock
