Find the part on the Chassis Electrical Equipment diagram for your 2025 Kawasaki Z900 Se ABS, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki Z900 Se ABS Chassis Electrical Equipment Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11058

BRACKET,MAGNETIC SWITCH

11058-1828

1
Out of stock

11058A

BRACKET

11058-1829

1
Out of stock

11058B

BRACKET,IMU

11058-1832

1
Out of stock

11058C

BRACKET

11058-1891

1
Out of stock

23062

BRACKET-COMP,VDS

23062-1544

1
Out of stock

23062A

BRACKET-COMP,A/C BOX

23062-1545

1
Out of stock

23062B

BRACKET-COMP,FORK UPPER HOLDER

23062-1546

1
Out of stock

26006

FUSE,MINI BLADE,15A,BLUE

26006-0001

1
Out of stock

26006A

FUSE,MINI BLADE,10A,RED

26006-1078

1
Out of stock

26006B

FUSE,MINI BLADE,30A,GREEN

26006-1080

1
Out of stock

26011

WIRE-LEAD,CONNECTOR COVER

26011-0275

1
Out of stock

26011A

WIRE-LEAD,BATTERY(-)

26011-0972

1
Out of stock

26011B

WIRE-LEAD,DIAG CONNECTOR

26011-1901

1
Out of stock

26011C

WIRE-LEAD,BATTERY(+)

26011-2483

1
Out of stock

26012

BATTERY,FTX9-BS,12V 8AH

26012-0608

1
Out of stock

26031

HARNESS,MAIN

26031-7052

1
Out of stock

27002

RELAY-ASSY

27002-0061

1
Out of stock

27002A

RELAY-ASSY

27002-1086

1
Out of stock

27003

HORN

27003-0121

1
Out of stock

39156

PAD,20X20X1

39156-2288

1
Out of stock

39156A

PAD,40X15X2

39156-2639

1
Out of stock

39156B

PAD,DIAG CONNECTOR

39156-2904

1
Out of stock

59221

CONNECTOR-CORD,USB TYPE-C

59221-0022

1
Out of stock

92039

RIVET,HOLE 8MM

92039-0014

1
Out of stock

92072

BAND,OS170-FT7(BLACK)

92072-1414

—
Out of stock

92075

DAMPER

92075-2097

1
Out of stock

92152

COLLAR,5.2X7.8X7.2

92152-2371

1
Out of stock

92154

BOLT,FLANGED,6X12

92154-1050

1
Out of stock

92154A

BOLT,SOCKET,6X10

92154-2667

1
Out of stock

92154B

BOLT,SOCKET,6X10

92154-4298

1
Out of stock

92161

DAMPER,RELAY BOX

92161-0203

1
Out of stock

92161A

DAMPER,25X40,T1.0

92161-1432

1
Out of stock

92161B

DAMPER

92161-2731

1
Out of stock

92171

CLAMP,L=60

92171-0652

1
Out of stock

92171A

CLAMP,EDGE CLIP

92171-1722

1
Out of stock

92172

SCREW,SOCKET,5X14

92172-0823

1
Out of stock

92173

CLAMP,12MM DIA.

92173-0736

1
Out of stock

92173A

CLAMP

92173-0861

1
Out of stock

92173B

CLAMP,CLIP,TAIL LAMP,ETC

92173-1429

1
Out of stock

92173C

CLAMP

92173-2198

1
Out of stock

92173D

CLAMP

92173-2199

1
Out of stock

120

BOLT-SOCKET,6X12

120CA0612

1
Out of stock

130

BOLT-FLANGED,5X14

130BA0514

1
Out of stock

130A

BOLT-FLANGED,6X10

130BA0610

1
Out of stock

130B

BOLT-FLANGED,6X16

130BA0616

1
Out of stock
