1990 Yamaha YSR50A (YSR50A) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1990 Yamaha YSR50A (YSR50A), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1990 Yamaha YSR50A (YSR50A) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

KICK AXLE ASSEMBLY

2AL-15660-00-00

1
Out of stock

2

GEAR, KICK (24T)

353-15641-00-00

1
Out of stock

3

CLIP

90468-26038-00

1
Out of stock

4

GUIDE, SPRING

4U1-15664-00-00

1
Out of stock

5

SPRING TORSION 304156650000

90508-26136-00

—
Out of stock

6

OIL SEAL (15X26X6-102)

93109-15001-00

1

$7.42

In stock

7

STOPPER, KICK SPRING

248-15668-00-00

1
Out of stock

8

GEAR, KICK IDLE

353-15651-00-00

1
Out of stock

9

WASHER PLATE 164185720000

90201-12166-00

1

$6.29

In stock

10

CIRCLIP(10Y)

99009-12400-00

1

$3.08

In stock

11

KICK CRANK ASSEMBLY

2AL-15620-00-00

1
Out of stock

12

BOLT, HEXAGON

97017-06025-00

1

$2.98

In stock
