1976 Kawasaki Trial Crankcase Diagram

← All diagrams

Find the part on the Crankcase diagram for your 1976 Kawasaki Trial, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1976 Kawasaki Trial Crankcase Diagram

#

Description
Price
Status
Order Qty

1

CRANKCASE SET

14001-067

Out of stock

2

STUD,10X25

172G1025

Out of stock

3

HOLDER,CRANK BEARING

14014-030

Out of stock

4

HOLDER,CRANK BEARING

14014-031

Out of stock

5

SCREW-CSK-CROS,6X14

221B0614

Out of stock

6

$1.32

In stock

7

CLAMP CABLE

92037-016

Out of stock

8

$1.54

In stock

9

SCREW PAN HEAD 6X65

220B0665

Out of stock

10

SCREW PAN HEAD 6X70

220B0670

Out of stock

11

PIN,DOWEL,10X14

92043-1037

$0.76

In stock

12

OIL SEAL,TB25457

653B254507

Out of stock

13

OIL SEAL TB32457

653B324507

$13.85

In stock

14

BEARING,BALL,#6305

92045-030

$37.96

In stock

15

CAP,CRANKCASE HOLE

92073-025

Out of stock

16

$10.76

In stock

17

$15.38

In stock

18

SEAL-OIL,TB3040

92050-033

Out of stock

19

$1.64

In stock

20

BREATHER ASSY

14069-1001

$22.77

In stock

21

TUBE,6X9X750

92059-1372

$14.65

In stock

22

GROMMET,BREATHER

92071-042

$3.39

In stock

23

BEARING,NEEDLE,344012

92046-040

Out of stock

24

SEAL-OIL,TB13225.5

92051-005

Out of stock
Crankshaft/piston →
