1985 Kawasaki KX500 Rear Suspension Diagram

← All diagrams

Find the part on the Rear Suspension diagram for your 1985 Kawasaki KX500, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1985 Kawasaki KX500 Rear Suspension Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11012

CAP

11012-1207

1
Out of stock

11012

CAP,ROD

11012-1418

1
Out of stock

35019

FLAP,ROD

35019-1166

1
Out of stock

39007

ARM-SUSP,UNI TRAK

39007-5006

1

$205.28

In stock

42036

SLEEVE,SUSPENSION AR

42036-1144

1
Out of stock

46102

ROD,UNI TRAK

46102-1130

1

$102.95

In stock

46102

ROD,UNI TRAK

46102-1131

1

$102.76

In stock

49001

NIPPLE-GREASE

49001-1051

1

$2.44

In stock

59266

JOINT-BALL,ROD

59266-1056

1
Out of stock

92001

BOLT,FLANGED,10X48

92001-1962

1

$3.14

In stock

92002

BOLT,FLANGED,14X57

92002-1390

1
Out of stock

92002

BOLT,ROD

92002-1394

1
Out of stock

92002B

BOLT,10X68

92002-1395

1

$14.53

In stock

92002C

BOLT,14X122

92002-1396

1

$38.47

In stock

92002D

BOLT,ROD,10X65

92002-1397

1
Out of stock

92002E

BOLT,6X14

92150-1340

1

$4.02

In stock

92015

NUT,14MM

92015-1407

1

$7.86

In stock

92015A

NUT,FLANGED,10MM

92015-1415

1

$3.72

In stock

92015B

NUT,14MM

92015-1463

1
Out of stock

92027

COLLAR,6.5X10.5X4.5

92027-1885

1

$5.42

In stock

92046

BEARING-NEEDLE

92046-1128

1
Out of stock

315

NUT-HEX-FINE

315G1400

1
Out of stock
