2020 Kawasaki JET SKI® SX-R™ Fuel Injection Diagram

← All diagrams

Find the part on the Fuel Injection diagram for your 2020 Kawasaki JET SKI® SX-R™, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2020 Kawasaki JET SKI® SX-R™ Fuel Injection Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11057

BRACKET

11057-0451

1

$62.00

In stock

11057A

1

$29.42

In stock

11060

GASKET

11060-3709

1

$12.76

In stock

13280

HOLDER,HARNESS

13280-3760

1

$3.25

In stock

21066

REGULATOR-VOLTAGE

21066-0755

1

$170.09

In stock

21175

1

$769.26

In stock

21176

SENSOR,TEMP

21176-0741

1

$85.48

In stock

26006

1

$4.16

In stock

26031

HARNESS,MAIN

26031-2572

1

$517.39

In stock

27002

RELAY-ASSY

27002-3703

1

$46.49

In stock

27010

SWITCH,MAGNETIC

27010-0860

1

$160.25

In stock

27010A

SWITCH,VDS

27010-3785

1

$264.90

In stock

53044

TRIM

53044-0621

1

$1.17

In stock

59416

CASE-ELECTRIC

59416-3765

1

$66.62

In stock

59416A

CASE-ELECTRIC

59416-3766

1

$67.97

In stock

92002

BOLT,6X25

92002-3714

1
Out of stock

92002A

BOLT,6X16

92002-3728

1
Out of stock

92002B

BOLT,6X12

92002-3763

1
Out of stock

92022

WASHER

92022-3035

1
Out of stock

92026

SPACER

92026-3703

1

$3.72

In stock

92037

CLAMP,L=100

92037-3736

1

$4.85

In stock

92043

PIN

92043-3715

1

$5.84

In stock

92071

GROMMET

92071-3004

1

$3.18

In stock

92071A

GROMMET

92071-3837

1

$2.61

In stock

92072

BAND,L=188.85

92072-0105

1

$1.51

In stock

92072A

BAND,L=372.24

92072-3883

1

$1.39

In stock

92150

BOLT,6X80

92150-3711

1

$12.42

In stock

92150A

BOLT,6X18

92150-3729

1

$3.72

In stock

92151

BOLT,6X14

92151-3788

1

$1.95

In stock

156

BOLT-WP,6X20

156R0620

1

$2.92

In stock

220

1

$2.00

In stock

311

NUT-HEX,6MM

311R0600

1

$0.75

In stock

410

1

$0.63

In stock

410A

1

$0.80

In stock
