Suzuki GSXR50 (1987) WIRING HARNESS Diagram

#

Description

Price

1

HARNESS, WIRING

36610-28B00

Unavailable

2

CLAMP (L:125)

09407-14403

$2.31

3

CLAMP (L:165)

09407-22404

Unavailable

4

LOCK ASSY,STEER | Includes Item(s) 5 - 6 This part replaces 37100-28B00.

37100-12B02

Unavailable

5

BOLT This part replaces 37152-47011.

07130-0616B

$2.44

6

LOCK WASHER This part replaces 08321-21067.

08321-01067

$1.89

7

KEY, BLANK | OPT This part replaces 37145-39300.

37145-16700

$13.53

8

SWITCH ASSY, ENGINE STOP

37830-13A00

Unavailable

9

WIRE, KILL SWITCH LEAD

36856-28B00

Unavailable

10

NO DESCRIPTION AVAILABLE This part replaces 37420-28B00.

37420-28B01

Unavailable
