Find the part on the Magneto diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Magneto Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

STATER ASSY | Includes Item(s) 2 - 10

32101-28B01

1
Out of stock

2

COIL, LIGHTING

32120-28B00

1
Out of stock

3

SCREW (4X30) This part replaces 02112-04308.

09125-04023

2
Out of stock

4

LOCK WASHER This part replaces 08321-21047.

08321-0104A

2
Out of stock

5

COIL, PRIMARY

32140-28B01

1
Out of stock

6

SCREW This part replaces 02112-04208.

02112-0420A

2
Out of stock

7

LOCK WASHER This part replaces 08321-21047.

08321-0104A

2
Out of stock

8

COIL, PICK UP

32150-28B00

1
Out of stock

9

2

$1.33

In stock

10

LOCK WASHER This part replaces 08321-21047.

08321-0104A

2
Out of stock

11

ROTOR

32102-09401

1
Out of stock

12

SCREW This part replaces 02142-05128.

02142-05127

3
Out of stock

13

NUT, WHEEL SET This part replaces 08316-16108.

08316-10107

1
Out of stock

14

KEY

08341-31039

1
Out of stock

15

CLAMP, LEAD WIRE

32371-30A00

1
Out of stock

16

SCREW This part replaces 02112-06108.

02112-06107

1
Out of stock
