1987 Suzuki GSXR50 Kick Starter Diagram

← All diagrams

Find the part on the Kick Starter diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Kick Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

SHAFT, KICK STARTER

26211-28B00

1
Out of stock

2

STARTER, KICK This part replaces 26231-09401.

26231-09410

1
Out of stock

3

GUIDE, SPRING

26221-09400

1
Out of stock

4

SPRING

09448-38004

1
Out of stock

5

GEAR, KICK DRIVE (NT:20)

26241-09401

1
Out of stock

6

WASHER, RH (14X22X1.0) This part replaces 08211-14221.

09181-14167

1
Out of stock

7

SPRING

09440-30007

1
Out of stock

8

OIL SEAL (14X24X6) This part replaces 09285-14001.

09285-14002

1
Out of stock

9

THRUST WASHER

08211-14321

1
Out of stock

10

GUIDE, KICK STARTER

26232-09400

1
Out of stock

11

STOPPER, KICK STARTER

26233-09400

1
Out of stock

12

BOLT This part replaces 01107-06127.

01500-06127

2
Out of stock

13

LEVER ASSY,KICK | Includes Item(s) 14 This part replaces 26300-28B00.

26300-04720

1
Out of stock

14

RUBBER,KICK STA This part replaces 26352-01000.

26352-01020

1
Out of stock

15

BOLT, GEAR SHIFT LINK This part replaces 01107-06205.

01500-0620A

1
Out of stock
