1987 Suzuki GSXR50 Cam Chain Diagram

← All diagrams

Find the part on the Cam Chain diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Cam Chain Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CHAIN,CAM SHAFT DRIVE This part replaces 12760-09402.

12760-02A00

1
Out of stock

2

GUIDE, CAM CHAIN

12771-09405

1
Out of stock

3

TENSIONER, CAM CHAIN

12811-09403

1

$34.57

In stock

4

BOLT (6X30) This part replaces 12812-09400.

09103-06246

1
Out of stock

5

GASKET

09168-06004

1
Out of stock

6

NO DESCRIPTION AVAILABLE | Includes Item(s) 7 - 11 This part replaces 12830-09411.

12830-09412

1
Out of stock

7

SPRING

09440-12032

1
Out of stock

8

BOLT

12838-09400

1
Out of stock

9

1

$1.55

In stock

10

1

$2.35

In stock

11

WASHER This part replaces 08322-11107.

08322-01107

1
Out of stock

13

2

$1.77

In stock
