Find the part on the Crankshaft diagram for your 1987 Suzuki GSXR50, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1987 Suzuki GSXR50 Crankshaft Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

NO DESCRIPTION AVAILABLE | Includes Item(s) 2 - 5 This part replaces 12200-28B00.

12200-28B01

1
Out of stock

2

ROD SET,CONNECT This part replaces 12200-09840.

12105-09811

1
Out of stock

3

BEARING (22X28X14) This part replaces 09263-22016-0B0.

09263-22072-0B0

1
Out of stock

4

CRANKSHAFT, RH

12221-28B00

1
Out of stock

5

CRANKSHAFT, LH

12260-09421

1
Out of stock

6

BEARING, LH

09262-35021-0A0

1
Out of stock

7

BEARING, RH

09262-20073

1
Out of stock

8

OIL SEAL (12X21X7) This part replaces 09282-12001.

09282-12009

1
Out of stock

9

GEAR, OIL PUMP DRIVE

16321-28B00

1
Out of stock

10

GEAR, PRIMARY DRIVE

21111-28B00

1
Out of stock

11

NUT This part replaces 09140-16014.

09140-16005

1
Out of stock

12

WASHER

09164-16005

1
Out of stock

13

KEY

09421-03005

1
Out of stock

14

RETAINER, OIL SEAL

12548-28B00

1
Out of stock

15

SCREW

02112-06087

2
Out of stock

16

PISTON This part replaces 12111-09407.

12111-09450-0F0

1
Out of stock

16

NO DESCRIPTION AVAILABLE | OPT This part replaces 12111-09407-050.

12100-09450-050

1
Out of stock

16

NO DESCRIPTION AVAILABLE | OPT This part replaces 12111-09407-100.

12100-09450-100

1
Out of stock

17

RING SET, PISTON

12140-09410

1
Out of stock

17

RING SET, PISTON (OS:0.5) | OPT

12140-09410-050

1
Out of stock

17

RING SET, PISTON (OS:1.0) | OPT

12140-09410-100

1
Out of stock

18

PIN,PISTON

12151-09400

1
Out of stock

19

SNAP RING

09381-12001

2
Out of stock

20

SHIM,20X30X0.6 (T:0.60) This part replaces 09181-20008.

09181-20187

1
Out of stock

20

SHIM,20X30X0.65 (T:0.65)

09181-20009

1
Out of stock

20

SHIM,20X30X0.7 (T:0.70) This part replaces 09181-20010.

09181-20188

1
Out of stock

20

SHIM,20X30X0.75 (T:0.75) This part replaces 09181-20011.

09181-20189

1
Out of stock

20

SHIM,20X30X0.8 (T:0.80) This part replaces 09181-20012.

09181-20190

1
Out of stock

20

SHIM,20X30X0.85 (T:0.85) This part replaces 09181-20013.

09181-20191

1
Out of stock

20

SHIM,20X30X0.9 (T:0.90) This part replaces 09181-20014.

09181-20192

1
Out of stock

20

SHIM,20X30X1.95 (T:0.95) This part replaces 09181-20015.

09181-20193

1
Out of stock

20

WASHER, REVERSE IDLE GEAR This part replaces 09181-20016.

09181-20195

1
Out of stock

20

SHIM,20X30X1.05 (T:1.05) This part replaces 09181-20017.

09181-20197

1
Out of stock

20

SHIM,20X30X1.1 (T:1.10) This part replaces 09181-20018.

09181-20200

1
Out of stock

20

SHIM,20X30X1.15 (T:1.15) This part replaces 09181-20019.

09181-20202

1
Out of stock

20

SHIM,20X30X1.2 (T:1.20) This part replaces 09181-20020.

09181-20204

1
Out of stock

20

SHIM,20X30X1.25 (T:1.25) This part replaces 09181-20021.

09181-20207

1
Out of stock

20

SHIM,20X30X1.3 (T:1.30) This part replaces 09181-20022.

09181-20209

1
Out of stock
