Suzuki GSXR50 (1987) CYLINDER Diagram

#

Description

Price

1

NO DESCRIPTION AVAILABLE This part replaces 11210-09408.

11211-09450-0F0

Unavailable

2

STUD BOLT (L:169)

09108-06054

Unavailable

3

STUD BOLT (L:175)

09108-06055

Unavailable

4

STUD BOLT This part replaces 01421-06208.

01421-0620A

$1.97

5

NUT This part replaces 09159-06017.

08319-31067

$2.09

6

GASKET, CYLINDER This part replaces 11241-09401.

11241-02A11

$8.91

7

PIN

09206-08001

$1.82

8

O RING, OIL GALLERY This part replaces 09280-12005.

09280-12012

$4.32
