Suzuki GS450GA (1985) RIGHT HANDLE SWITCH Diagram

#

Description

Price

1

GRIP, THROTTLE This part replaces 57110-15500.

57110-49501

$33.46

2

SWITHCH ASSY, RH | Includes Item(s) 3

37200-49471

Unavailable

3

SCREW This part replaces 37591-49210.

09125-05102

$1.61

4

LEVER, BRAKE

57420-49101

$32.45

5

BOLT

57431-49100

Unavailable

6

.NUT This part replaces 08319-21065.

08319-2106B

$2.38

7

SWITCH ASSY, ST This part replaces 57460-49300.

57460-45500

$34.66

8

BAND (L:120)

09407-12402

$2.82
