Find the part on the Instrument Panel ET250E diagram for your 1979 Yamaha ET250C, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Yamaha ET250C Instrument Panel ET250E Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

PANEL, INSTRUMENT

8G5-77711-00-00

1
Out of stock

2

INDICATOR 3

8A1-77743-00-00

1
Out of stock

3

INDICATOR 4

878-77744-00-00

1
Out of stock

4

INDICATOR 4

8A1-77744-00-00

1
Out of stock

5

INDICATOR 1

(8L2-77741-00-00)

1
Out of stock

6

LABEL, WARNING 7

8L2-77767-00-00

1
Out of stock

7

INDICATOR, COCK

(8L2-24153-00-00)

1
Out of stock

8

PANEL, INSTRUMENT

8F3-77712-00-00

1
Out of stock

9

HINGE 1

8F3-77726-01-00

1
Out of stock

10

UNAVAILABLE IN PRICE BOOK

8F3-77726-00-00

1
Out of stock

11

SCREW,PAN HEAD (646)

98580-05012-00

1

$5.60

In stock

12

WASHER, PLAIN (646)

92990-05600-00

1
Out of stock

13

YBS67-5 WASHER, SPRING

92990-05100-00

1
Out of stock

14

NUT, HEXAGON (663)

95380-05600-00

1

$6.17

In stock

15

SPRING, TENSION

90506-10090-00

1
Out of stock

16

DAMPER 1

(811-77461-00-00)

1
Out of stock

17

SCREW, PAN

98507-06014-00

—

$6.18

In stock

18

WASHER, PLATE 8221447500

90201-06057-00

—
Out of stock

19

WASHER, SPRING

92907-06100-00

—
Out of stock

20

GROMMET

8F3-77746-00-00

1
Out of stock
