Find the part on the Starter diagram for your 1978 Yamaha XT500 (XT500E), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1978 Yamaha XT500 (XT500E) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

KICK CRANK ASSY

1JN-15610-00-00

—

$233.95

In stock

2

COVER, KICK CRANK

1T1-15618-00-00

1
Out of stock

3

BOSS, KICK CRANK

583-15621-00-00

1
Out of stock

4

WASHER PLATE 278156130000

90201-15234-00

1

$6.78

In stock

5

CIRCLIP

99006-10600-00

1

$6.91

In stock

6

BALL (12R)

93507-32031-00

1
Out of stock

7

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

8

BOLT, HEXAGON

97013-08030-00

1

$3.20

In stock

9

OIL SEAL (25X35X7-256)

93102-25064-00

1
Out of stock

10

WASHER, PLATE(1FK)

90201-256K6-00

—

$3.49

In stock

11

CIRCLIP(JF7)

99009-25400-00

1

$6.68

In stock

12

SPACER

(90560-25154-00)

1
Out of stock

13

SPRING, TORSION (583 KICK)

90508-32280-00

1
Out of stock

14

COVER, SPRING

(583-15676-00-00)

1
Out of stock

15

CIRCLIP (4L0)

93440-25084-00

1

$3.96

In stock

16

GEAR, KICK

583-15641-00-00

—
Out of stock

17

WASHER, PLATE(59W)

90201-253K0-00

—

$6.18

In stock

18

CIRCLIP

93440-25020-00

—
Out of stock

19

WHEEL, RACHET

583-15671-00-00

—
Out of stock

20

SPRING COMPRESSION363156750000

90501-23143-00

—
Out of stock

21

COVER, SPRING

363-15676-00-00

—
Out of stock

22

CIRCLIP(1EY)

99009-19400-00

—

$6.17

In stock

23

WASHER PLATE 168171160000

90201-20278-00

—
Out of stock

24

AXLE, KICK

583-15661-00-00

—
Out of stock

25

STOPPER

434-15668-00-00

—
Out of stock

26

GUIDE, RACHET WHEEL

583-15674-00-00

—
Out of stock

27

WASHER, LOCK

363-15686-00-00

—
Out of stock

28

BOLT, HEXAGON DEEP RECESS

97D95-06016-00

—

$1.91

In stock
