Find the part on the Headlight diagram for your 2020 Kawasaki W800, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2020 Kawasaki W800 Headlight Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11057

BRACKET

11057-2298

1

$3.76

In stock

11057A

1

$15.59

In stock

11057B

BRACKET,ABS SENSOR

11057-2856

1

$4.34

In stock

23004

LAMP-HEAD,LED

23004-0390

1

$1,133.36

In stock

23005

BODY-COMP-HEAD LAMP,EBONY

23005-0049-H8

1
Out of stock

23006

RIM-LAMP

23006-0019

1
Out of stock

39156

PAD

39156-2565

1

$12.56

In stock

92009

SCREW,ADJUST,5X55

92009-1683

1

$5.76

In stock

92015

NUT,FLANGED,8MM

92015-1014

1
Out of stock

92015A

NUT,5MM

92015-1897

1
Out of stock

92075

DAMPER

92075-1736

1

$5.21

In stock

92145

SPRING

92145-1887

1

$20.51

In stock

92151

BOLT,FLANGED,8X35

92151-1537

1

$2.19

In stock

92152

COLLAR,8X12X20.3

92152-2433

1
Out of stock

92154

BOLT,SOCKET,5X12

92154-0917

1

$3.74

In stock

92172

SCREW,TAPPING,5X12

92172-0239

1

$0.97

In stock

92172A

SCREW,TAPPING,5X10

92172-0262

1

$1.20

In stock

92173

CLAMP,12MM DIA.

92173-0736

1

$4.01

In stock

92200

WASHER,NYLON,5.3X11.5X0.5

92200-1480

1
Out of stock

92200A

WASHER

92200-2282

1

$4.08

In stock

92210

NUT

92210-0571

1
Out of stock

120

BOLT-SOCKET,6X16

120CC0616

1

$1.97

In stock
