Suzuki VZ800 (2009) HANDLE SWITCH (MODEL K7/K8/K9) Diagram

#

Description

Price

1

SWITCH ASSY, HANDLE, RH | MODEL K7/K8 This part replaces 37200-48G30.

37200-48GA1

$292.68

1

SWITCH ASSY, HANDLE, RH | MODEL K9; Includes Item(s) 2 - 4 This part replaces 37200-48GA0.

37200-48GA1

$292.68

2

SCREW

02112-0510A

$1.46

3

SCREW This part replaces 02112-05353.

02112-0535B

$2.01

4

.SCREW This part replaces 02112-05453.

02112-0545B

$2.32

5

SWITCH ASSY, HANDLE LH | Includes Item(s) 6 - 7

37400-48G10

$341.00

6

SCREW

02112-0530A

$1.93

7

.SCREW This part replaces 02112-05453.

02112-0545B

$2.32

8

CLAMP (L:145)

09407-14407

$2.84
