2013 Kawasaki TERYX4™ 750 4x4 EPS Generator Diagram

← All diagrams

Find the part on the Generator diagram for your 2013 Kawasaki TERYX4™ 750 4x4 EPS, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2013 Kawasaki TERYX4™ 750 4x4 EPS Generator Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

130

BOLT-FLANGED,5X14

130BA0514

1

$1.73

In stock

130A

BOLT-FLANGED,6X22

130BA0622

1

$1.17

In stock

13272

PLATE

13272-1222

1

$3.20

In stock

21003

STATOR

21003-0108

1
Out of stock

21007

ROTOR

21007-0565

1
Out of stock

21066

REGULATOR-VOLTAGE

21066-0022

1
Out of stock

510

KEY-WOODRUFF

510A4200

1
Out of stock

92153

BOLT,FLANGED,12X45

92153-0951

1
Out of stock

92154

BOLT,TORX,6X35

92154-1007

1
Out of stock
