Suzuki SV650 (2007) HANDLEBAR (WITH COWLING) Diagram

#

Description
Price

1

HANDLEBAR, RH

56111-17G00

Unavailable

2

HANDLEBAR, LH

56151-17G00

$344.58

3

BOLT

56123-35F00

$6.95

4

BALANCER SET,HA | Includes Item(s) 5 - 10 This part replaces 56200-16830.

56200-16834

$50.48

5

SCREW This part replaces 02122-06953.

02122-0695B

$4.10

6

EXPANDER,HANDLE This part replaces 56272-23F00.

56272-23F20

$3.22

7

SPACER

56276-17D00

$4.78

8

.WASHER (6.5X16X1.6)

09160-06130

$1.89

9

.EXPANDER,HANDLE BALANCER This part replaces 56272-10G00.

56272-10G01

$4.44

10

NUT This part replaces 56273-10G00.

56273-10G10

$7.92

11

MIRROR ASSY, REAR VIEW RH | MODEL K3/K4/K5 This part replaces 56500-16G00.

56500-16G10

$213.06

11

MIRROR ASSY, REAR VIEW RH | MODEL K6/K7

56500-16G10

$213.06

12

MIRROR ASSY, REAR VIEW LH | MODEL K3/K4/K5 This part replaces 56600-16G00.

56600-16G10

$131.45

12

MIRROR ASSY, REAR VIEW LH | MODEL K6/K7

56600-16G10

$131.45

13

CUSHION

94576-24F00

$6.14

14

BOLT This part replaces 07130-06163.

07130-0616B

$2.38

15

CAP

09250-05009

$2.10

16

CABLE ASSY, CLUTCH

58200-17G10

$27.12

17

CABLE ASSY,THRO This part replaces 58300-16G10.

58300-16G11

$50.15

18

GUIDE, CABLE LH | MODEL K3/K4/K5/K6

58621-16GA0

Unavailable

18

GUIDE, CABLE LH | MODEL K7

58621-16GC0

Unavailable

19

BOLT, CLAMP This part replaces 01550-06123.

01550-0612A

$1.97

20

GUIDE, THROTTLE CABLE

58621-16GB0

Unavailable
