1979 Yamaha SRX440C Instrument Panel Diagram

← All diagrams

Find the part on the Instrument Panel diagram for your 1979 Yamaha SRX440C, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Yamaha SRX440C Instrument Panel Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

PANEL, INSTRUMENT

8G9-77711-00-00

1
Out of stock

2

INDICATOR 1

(878-77741-00-00)

1
Out of stock

3

INDICATOR 3

(8J0-77743-00-00)

1
Out of stock

4

BOLT(8CP)

97017-06014-00

1

$5.12

In stock

5

WASHER, PLAIN (646)

92990-06600-00

1

$2.48

In stock

6

CABLE, STARTER 1

8G9-26331-00-00

1
Out of stock

7

CABLE, STARTER 2

8A7-26334-00-00

1
Out of stock

8

CONNECTOR, CABLE

137-26261-01-00

—
Out of stock

9

PANEL, INSTRUMENT

(8G9-77712-00-00)

1
Out of stock

10

NUT, HEXAGON (663)

95380-05600-00

1

$6.17

In stock

11

WASHER, PLAIN (646)

92990-05600-00

1
Out of stock

12

YBS67-5 WASHER, SPRING

92990-05100-00

1
Out of stock

13

LOUVER 6

8A5-77108-30-00

1
Out of stock

14

NUT 6504269100

90183-05003-00

1
Out of stock

15

EMBLEM 3

838-77143-00-00

1
Out of stock
