1976 Yamaha SRX440 Intake Diagram

← All diagrams

Find the part on the Intake diagram for your 1976 Yamaha SRX440, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1976 Yamaha SRX440 Intake Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

BOLT, HEXAGON

97013-08020-00

1

$1.54

In stock

2

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock

3

MANIFOLD, INTAKE

(8A7-13555-00-00)

1
Out of stock

3

MANIFOLD, INTAKE

84M-13555-00-00

1
Out of stock

4

MANIFOLD, INTAKE

(8A7-13555-00-00)

1
Out of stock

5

SPRING, TENSION (90507-12014)

90507-12041-00

1
Out of stock

6

SILENCER, INTAKE 2

(8A7-14441-01-00)

1
Out of stock

7

GUIDE, ELEMENT

8A7-14458-00-00

1
Out of stock

8

JOINT, AIR CLNR 1

(8A7-14453-00-00)

1
Out of stock

8

JOINT, AIR CLNR 1

(8A8-14453-00-00)

1
Out of stock

9

STAY 2

(8A7-14499-00-00)

1
Out of stock

10

PIPE

(8A7-14465-00-00)

1
Out of stock

11

GROMMET

(90480-14183-00)

1
Out of stock

12

COLLAR(735)

90387-06033-00

1

$6.68

In stock

13

BOLT, HEXAGON

97017-06025-00

1

$2.98

In stock

14

WASHER, PLATE

90201-06M02-00

1

$2.23

In stock

15

STAY 2

8A7-14494-00-00

1
Out of stock

16

CLAMP, HOSE

90460-70080-00

1
Out of stock

17

BOLT, HEXAGON

97017-06020-00

—

$2.55

In stock

18

BOLT, HEXAGON

97017-06030-00

—

$3.00

In stock

19

WASHER, SPRING

92995-06100-00

1

$2.99

In stock

20

WASHER, PLAIN (646)

92990-06600-00

—

$2.48

In stock

21

HOSE

(90445-09102-00)

1
Out of stock

22

NUT, AJUSTING

8A7-26323-00-00

1
Out of stock

23

BAND

86M-13575-00-00

—

$16.45

In stock

23

CLAMP, HOSE

90460-60084-00

1
Out of stock
