2002 Kawasaki Prairie 300 Gear Change Drum/shift Fork Diagram

← All diagrams

Find the part on the Gear Change Drum/shift Fork diagram for your 2002 Kawasaki Prairie 300, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2002 Kawasaki Prairie 300 Gear Change Drum/shift Fork Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13107

SHAFT,IDLER

13107-1414

1
Out of stock

13139

SHIFTER,FORWARD HI&REVERSE

13139-1086

1
Out of stock

13260

GEAR,FORWARD HIGH,43T

13260-1766

1
Out of stock

13260A

GEAR,FORWARD LOW,48T

13260-1767

1
Out of stock

13260B

GEAR,IDLE SHAFT,36T

13260-1769

1
Out of stock

39135

SPROCKET-DRIVEN,REVERSE,37T

39135-1059

1
Out of stock

92022

WASHER,28.1X34X1.0

92022-1731

1
Out of stock

92026

SPACER,20.3X30X1.8

92026-1066

1
Out of stock

92033

RING-SNAP,24MM

92033-026

1
Out of stock

92033A

RING-SNAP,25.9X30.6X1.2

92033-1037

1
Out of stock

92200

WASHER,24.2X32X0.50

92200-1400

1
Out of stock

92200A

WASHER,24.2X32X1.00

92200-1412

1
Out of stock
