1997 Kawasaki Ninja® ZX™-6R Battery Case Diagram

← All diagrams

Find the part on the Battery Case diagram for your 1997 Kawasaki Ninja® ZX™-6R, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1997 Kawasaki Ninja® ZX™-6R Battery Case Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

130

BOLT-FLANGED,6X14,BLACK

130J0614

1
Out of stock

130A

BOLT-FLANGED,8X30

130J0830

1
Out of stock

550

PIN-COTTER,4.0X25

550D4025

1
Out of stock

11012

CAP,BUNGEE CORD HOOK

11012-1589

1
Out of stock

11012A

CAP

11012-1844

1
Out of stock

11048

BRACKET,FUEL PUMP

11048-1859

1
Out of stock

11048A

BRACKET,RADIATOR

11048-1860

1
Out of stock

27012

HOOK,BUNGEE CORD,RR

27012-1475

1
Out of stock

27012A

HOOK,HELMET,LH

27012-1505

1
Out of stock

27012B

HOOK,HELMET,RH

27012-1506

1
Out of stock

32037

BRACKET-SHOCKABSORBER

32037-1657

1
Out of stock

34003

HOLDER-STEP

34003-1327

1
Out of stock

35011

STAY,FR,LH

35011-1552

1
Out of stock

35011A

STAY,FR,RH

35011-1553

1
Out of stock

35011B

STAY,REAR STEP,LH

35011-1736

1
Out of stock

35011C

STAY,REAR STEP,RH

35011-1737

1
Out of stock

46075A

GRIP,RR,LH,F.BLACK

46075-1115-21

1
Out of stock

46075C

GRIP,RR,RH,F.BLACK

46075-1116-21

1

$54.98

In stock

92015

NUT,FLANGED,16MM

92015-1881

1
Out of stock

92015A

NUT,16MM

92015-1953

1
Out of stock

92150

BOLT,SOCKET,10X25

92150-1268

1
Out of stock

92150A

BOLT,SOCKET,8X20

92150-1839

1
Out of stock
