Kawasaki Ninja ZX-4R ABS Ignition Switch/Locks/Reflectors Diagram

#

Description
Price

11056

BRACKET,SEAT LOCK

11056-2119

$3.93

11057

BRACKET,SEAT LOCK CABLE

11057-3928

$4.32

11057A

BRACKET,SIDE STAND SWITCH

11057-7089

$2.64

11057B

BRACKET,SEAT LOCK,UPP

11057-7740

$1.76

11058

BRACKET,HELMET-LOCK

11058-0256

$5.12

11058A

BRACKET,RR SIDE REFLECTOR

11058-0625

$12.51

27005

SWITCH-ASSY-IGNITION

27005-0725

$181.84

27005A

SWITCH-ASSY-IGNITION

27005-5197

$495.83

27008

KEY-LOCK,BLANK

27008-0662

$25.56

27010

SWITCH,SIDE STAND

27010-0097

$119.84

27010A

SWITCH,STOP

27010-0863

$29.63

27016

LOCK-ASSY,SEAT STRIKER

27016-0008

$14.14

27016A

LOCK-ASSY,SEAT STRIKER

27016-0093

$29.92

27016B

LOCK-ASSY,HELMET

27016-5423

$112.47

27016C

LOCK-ASSY,SEAT

27016-5424

$137.10

27016D

LOCK-ASSY,TANK CAP

27016-5425

$128.97

28012

REFLECTOR-REFLEX,FR,SIDE

28012-0001

$19.59

28012A

REFLECTOR-REFLEX

28012-0002

$19.59

28012B

REFLECTOR-REFLEX

28012-1077

$21.76

39156

PAD,25X33X1

39156-2158

$1.34

54010

CABLE

54010-0641

$10.53

55020

GUARD,SEAT STRIKER

55020-2246

$9.81

55020A

GUARD

55020-2404

$2.25

56054

MARK,IGNITION SWITCH

56054-3854

$10.49

92015

NUT,FLANGED,6MM

92015-1367

$2.53

92075

DAMPER

92075-1564

$4.15

92145

SPRING,BRAKE LAMP SWITCH

92145-0683

$2.79

92151

BOLT,SOCKET,6X14

92151-1654

$1.24

92152

COLLAR,6X9X10.6

92152-1971

$11.44

92152A

COLLAR,6.5X9.5X17

92152-2274

$2.02

92154

BOLT,SOCKET,4X10

92154-0039

$1.81

92154A

BOLT,TORX,6X20

92154-0377

$3.10

92154B

BOLT,SOCKET,6X40

92154-0505

$1.44

92154C

BOLT,FLANGED-SMALL,6X16,TB2468

92154-3869

Unavailable

92161

DAMPER

92161-0117

$2.36

92161A

DAMPER

92161-0118

$2.36

92161B

DAMPER

92161-2336

$1.61

92171

CLAMP

92171-0534

$5.56

92172

SCREW,HEXLOBE,6X30

92172-1378

$1.78

92200

WASHER,6X20X1.6

92200-0780

$0.95

92200A

WASHER,6.5X20X1.6

92200-1962

$3.29

92210

NUT,FLANGED,5MM

92210-0007

$1.90

130

BOLT-FLANGED,6X16

130BA0616

$0.97

132

BOLT-FLANGED-SMALL,6X14

132BC0614

$0.76

220

SCREW-PAN-CROS,6X25

220AC0625

$1.10

311

NUT-HEX,5MM

311AB0500

$0.46

410

W-PLAIN-S,4MM

410AB0400

$0.73
