Find the part on the Footrest diagram for your 2009 Suzuki LT-R450, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2009 Suzuki LT-R450 Footrest Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

FOOTREST, RH

43510-45G00

1
Out of stock

2

FOOTERST, LH

43520-45G00

1
Out of stock

3

BOLT, UPPER | MODEL K6/K7 This part replaces 09103-10378-A05.

09103-10378

4
Out of stock

3

BOLT | MODEL K8/K9

09103-10378

4
Out of stock

4

REINFORCE, MUDGUARD RH | MODEL K6/K7 This part replaces 43570-45G00.

43570-45G10

1
Out of stock

4

REINFORCE, MUDGUARD RH | MODEL K8/K9

43570-45G10

1
Out of stock

5

REINFORCE, MUDGUARD LH | MODEL K6/K7 This part replaces 43580-45G00.

43580-45G10

1
Out of stock

5

REINFORCE, MUDGUARD LH | MODEL K8/K9

43580-45G10

1
Out of stock

6

BOLT, FRONT

01547-0616A

4
Out of stock

7

NUT

08319-3106A

4
Out of stock

8

BOLT (8X16) This part replaces 09103-08283-A05.

09103-08570

2
Out of stock

9

1

$482.73

In stock

10

BOLT

01550-0820A

4
Out of stock

11

GRIP, FRONT | MODEL K6/K7 This part replaces 43990-45G00.

43990-45G10

1
Out of stock

11

GRIP, FRONT | MODEL K8/K9

43990-45G10

1
Out of stock

12

BOLT (8X16)

01550-0816A

4
Out of stock
