2025 Kawasaki KLR650 S Engine Mount Diagram

← All diagrams

Find the part on the Engine Mount diagram for your 2025 Kawasaki KLR650 S, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki KLR650 S Engine Mount Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13272

PLATE

13272-3910

1

$3.90

In stock

32190

BRACKET-ENGINE,LWR

32190-0858

1

$22.56

In stock

32190A

BRACKET-ENGINE,UPP

32190-0859

1

$21.12

In stock

32190B

BRACKET-ENGINE

32190-0860

1

$12.71

In stock

92001

BOLT,10X75

92001-4021

1

$8.63

In stock

92002

BOLT,10X145

92002-1348

1

$17.39

In stock

92015

NUT,FLANGED,8MM

92015-1406

1

$3.53

In stock

92015A

NUT,FLANGED,10MM

92015-1415

1

$3.72

In stock

92150

BOLT,8X80

92150-1162

1

$5.75

In stock

92151

BOLT,8X50

92151-1463

1

$4.23

In stock

92154

BOLT,FLANGED,8X45

92154-3733

1
Out of stock

92210

NUT,FLANGED,LOCK,8MM

92210-0159

1
Out of stock

92210A

NUT,PLATE,8MM

92210-0608

1
Out of stock
