1977 Yamaha IT400D (IT400D) Crank Piston Diagram

← All diagrams

Find the part on the Crank Piston diagram for your 1977 Yamaha IT400D (IT400D), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1977 Yamaha IT400D (IT400D) Crank Piston Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CRANKSHAFT ASSEMBLY

(1W3-11400-00-00)

1
Out of stock

1

CRANKSHAFT ASSEMBLY

(2K8-11400-00-00)

1
Out of stock

1

CRANKSHAFT ASSEMBLY

(2K8-11400-00-00)

1
Out of stock

2

CRANK 1

(1W3-11412-00-00)

1
Out of stock

2

CRANK 1

(1W4-11412-00-00)

1
Out of stock

2

CRANK 1

(2K8-11412-00-00)

1
Out of stock

2

CRANK 1

(2K8-11412-00-00)

1
Out of stock

3

CRANK 2

(1W3-11422-00-00)

1
Out of stock

3

CRANK 2

(1W4-11422-00-00)

1
Out of stock

3

CRANK 2

(2K8-11422-00-00)

1
Out of stock

3

CRANK 2

(2K8-11422-00-00)

1
Out of stock

4

. ROD, CONNECTING

431-11651-00-00

1
Out of stock

4

.. ROD, CONNECTING

498-11651-00-00

1
Out of stock

4

CONNECTING ROD ASSEMBLY

510-11650-01-00

1
Out of stock

4

CONNECTING ROD ASSY

5X5-11650-00-00

—

$313.75

In stock

5

PIN, CRANK

2X4-11681-00-00

—

$73.68

In stock

6

BEARING, CYLINDRICAL(4JW)

93310-425P2-00

—

$66.55

In stock

7

WASHER 275116850000

90209-25085-00

—

$10.43

In stock

8

PISTON STD

(1W5-11631-00-96)

1
Out of stock

8

PISTON 1 O/S 0.25

1W5-11635-00-00

1
Out of stock

8

PISTON 2 O/S 0.50

1W5-11636-00-00

1
Out of stock

8

PISTON 3 O/S 0.75

(1W5-11637-00-00)

1
Out of stock

8

PISTON 4 O/S 1.00

(1W5-11638-00-00)

1
Out of stock

8

PISTON STD

(1W6-11631-00-96)

1
Out of stock

8

PISTON 1 O/S 0.25

1W6-11635-00-00

1
Out of stock

8

PISTON 2 O/S 0.50

1W6-11636-00-00

1
Out of stock

8

PISTON 3 O/S 0.75

1W6-11637-00-00

1
Out of stock

8

PISTON 4 O/S 1.00

1W6-11638-00-00

1
Out of stock

9

PISTON RINGSET STD (2X7-11610-00)

1W5-11610-00-00

1
Out of stock

9

PISTON RINGSET 1ST (2X7-11610-10)

1W5-11610-10-00

1
Out of stock

9

PISTON RINGSET 2ND (2X7-11610-20)

1W5-11610-20-00

1
Out of stock

9

PISTON RINGSET 3RD (2X7-11610-30)

1W5-11610-30-00

1
Out of stock

9

PISTON RINGSET 4TH (2X7-11610-40)

1W5-11610-40-00

1
Out of stock

9

PISTON RINGSET STD

1W6-11610-00-00

1
Out of stock

9

PISTON RINGSET 1ST

1W6-11610-10-00

1
Out of stock

9

PISTON RINGSET 2ND

1W6-11610-20-00

1
Out of stock

9

PISTON RINGSET 3RD

1W6-11610-30-00

1
Out of stock

9

PISTON RINGSET 4TH

1W6-11610-40-00

1
Out of stock

10

—

$32.87

In stock

11

PIN, PISTON

214-11633-00-00

—

$27.84

In stock

11

PIN, PISTON

275-11633-00-00

—

$30.66

In stock

12

CLIP 6041163400

93450-20026-00

—

$5.10

In stock

13

BEARING (5X5)

93306-20627-00

—

$66.08

In stock

13

BRG,R-B 6306 72MM 351G KY

93306-30615-00

—

$72.96

In stock

14

OIL SEAL(38V)

93103-30150-00

—

$19.71

In stock

15

OIL SEAL (434)

93103-40091-00

—

$27.25

In stock

16

O-RING (498)

93210-29282-00

—
Out of stock

17

GEAR, PRI DRIVE

(1W3-16111-00-00)

1
Out of stock

17

GEAR, PRI DRIVE

(1W4-16111-00-00)

1
Out of stock

18

WASHER(N15)

92907-18100-00

—

$7.09

In stock

19

NUT (498)

90179-18172-00

—
Out of stock

20

KEY, WOODRUFF

90280-05001-00

—

$10.68

In stock

21

KEY, STRAIGHT (498)

90282-07019-00

—

$8.69

In stock

22

NUT(55K)

90170-12347-00

—

$8.43

In stock

23

YBS67-12 WASHER,SPRING

92990-12100-00

—

$6.68

In stock

24

WASHER, PLATE (583)

90201-12593-00

—

$6.82

In stock
