1986 Yamaha IT200 (IT200S) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1986 Yamaha IT200 (IT200S), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1986 Yamaha IT200 (IT200S) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GEAR, KICK IDLE

43G-15651-00-00

1
Out of stock

2

SHIM, MAIN AXLE 0.5MM

137-17417-00-05

1

$4.12

In stock

3

CIRCLIP

93440-15012-00

1
Out of stock

4

KICK AXLE ASSEMBLY

39W-15660-00-00

1
Out of stock

5

GEAR, KICK

3R3-15641-00-00

1
Out of stock

6

CLIP 315156870000

90468-26048-00

1
Out of stock

7

HOLDER, KICK GEAR

248-15654-00-00

1

$6.49

In stock

8

CIRCLIP(4A6)

99009-30400-00

1

$6.55

In stock

9

SPACER

3R3-15666-00-00

1
Out of stock

10

SPRING, TORSION

90508-26427-00

1
Out of stock

11

CIRCLIP (525)

93410-17037-00

1

$6.68

In stock

12

OIL SEAL (15A)

93102-17263-00

1

$8.91

In stock

13

KICK CRANK ASSEMBLY

43G-15620-00-00

1
Out of stock

14

BOSS, KICK CRANK

(5X3-15621-00-00)

1
Out of stock

15

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

16

BALL (12R)

93507-32031-00

—
Out of stock

17

. PIN, CLEVIS

91702-12040-00

1
Out of stock

18

. COVER, KICK LEVER

3R3-15618-01-00

1
Out of stock

19

. PIN, COTTER

91401-40020-00

1
Out of stock

20

NUT, FLANGE(3BM)

95704-10500-00

—

$1.71

In stock
