1982 Suzuki GS650GL Left Handle Switch Diagram

← All diagrams

Find the part on the Left Handle Switch diagram for your 1982 Suzuki GS650GL, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Suzuki GS650GL Left Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, LH This part replaces 57211-44100.

57211-49500

1
Out of stock

2

CAP, GRIP END LH

57216-49100

1
Out of stock

3

LEVER ASSY,CLUT | Includes Item(s) 4 - 14 This part replaces 57500-49112.

57500-49301

1
Out of stock

4

LEVER, CLUTCH

57620-49111

1
Out of stock

5

BOLT This part replaces 57431-11011.

57431-11013

1
Out of stock

6

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

7

ADJUSTER, CABLE

57441-11010

1
Out of stock

8

NUT

57442-11010

1
Out of stock

9

BOLT

57451-49100

1
Out of stock

10

HOLDER

57465-18601

1
Out of stock

11

COVER

57481-33010

1
Out of stock

12

SCREW This part replaces 09125-03105.

09125-03105-XC0

2
Out of stock

13

WASHER,LOCK This part replaces 08321-21038.

09162-03001

2
Out of stock

14

WASHER This part replaces 08322-21038.

08322-01037

2
Out of stock

15

SWITCH ASSY,HAN | Includes Item(s) 16 - 20 This part replaces 37400-45960.

37400-45963

1
Out of stock

16

LEVER, STARTER This part replaces 58721-27502.

58721-27503

1
Out of stock

17

WASHER

58722-03010

1
Out of stock

18

BODY This part replaces 37572-49440.

37572-49441

1
Out of stock

19

SCREW This part replaces 37574-49440.

02112-7516A

1
Out of stock

20

SCREW This part replaces 02112-05165.

02112-05164

2
Out of stock

21

COVER, CLUTCH LEVER

57661-31000

1
Out of stock

22

BOOT, CLUTCH CABLE This part replaces 58273-31000.

58273-31001

1
Out of stock

23

BAND (L:120)

09407-12402

2
Out of stock
