1982 Suzuki GS450L Right Handle Switch (Model T Diagram

← All diagrams

Find the part on the Right Handle Switch (Model T diagram for your 1982 Suzuki GS450L, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Suzuki GS450L Right Handle Switch (Model T Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP ASSY, THROTTLE | Includes Item(s) 2 - 6 This part replaces 57100-47011.

57100-47500

1
Out of stock

2

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

1
Out of stock

3

BUTTON, STARTING | MODEL T

57371-45000

1
Out of stock

4

CONTACT

57372-45000

1
Out of stock

5

SPRING

57382-45000

1
Out of stock

6

SCREW This part replaces 02112-05258.

02112-05257

2
Out of stock

7

GRIP, THROTTLE | MODEL X This part replaces 57110-44011.

57110-49510

1
Out of stock

8

GRIP ASSY, THROTTLE | MODEL X; Includes Item(s) 9 - 12 This part replaces 57100-44130.

57100-47500

1
Out of stock

9

BUTTON, STARTING | MODEL X

57371-45000

1
Out of stock

10

CONTACT | MODEL X

57372-45000

1
Out of stock

11

SPRING | MODEL X

57382-45000

1
Out of stock

12

SCREW | MODEL X This part replaces 02112-05258.

02112-05257

2
Out of stock

13

CAP, GRIP END RH

57215-49100

1
Out of stock

14

LEVER, BRAKE

57420-49101

1
Out of stock

15

BOLT

57431-18621

1
Out of stock

16

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

17

SWITCH ASSY, ST | Includes Item(s) 18 - 24 This part replaces 57460-49100.

57460-45500

1
Out of stock

18

HOLDER This part replaces 57461-18600.

57465-18601

1
Out of stock

19

HOLDER This part replaces 57462-18600.

57465-18601

1
Out of stock

20

HOLDER This part replaces 57463-18600.

57465-18601

1
Out of stock

21

COVER

57481-33010

1
Out of stock

22

SCREW This part replaces 09125-03105.

09125-03105-XC0

2
Out of stock

23

WASHER,LOCK This part replaces 08321-21038.

09162-03001

2
Out of stock

24

WASHER This part replaces 08322-21038.

08322-01037

2
Out of stock

25

BAND (L.120)

09407-12402

2
Out of stock
