1982 Suzuki GS450L Left Handle Switch (Model T Diagram

← All diagrams

Find the part on the Left Handle Switch (Model T diagram for your 1982 Suzuki GS450L, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1982 Suzuki GS450L Left Handle Switch (Model T Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, LH This part replaces 57211-44100.

57211-49500

1
Out of stock

2

CAP, GRIP END LH

57216-49100

1
Out of stock

3

LEVER ASSY,CLUT | Includes Item(s) 4 - 16 This part replaces 57500-49111.

57500-49301

1
Out of stock

4

LEVER, CLUTCH

57620-49111

1
Out of stock

5

BOLT This part replaces 57431-11011.

57431-11013

1
Out of stock

6

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

7

ADJUSTER, CABLE

57441-11010

1
Out of stock

8

NUT

57442-11010

1
Out of stock

9

BOLT

57451-49100

1
Out of stock

10

HOLDER This part replaces 57461-18600.

57465-18601

1
Out of stock

11

HOLDER This part replaces 57462-18600.

57465-18601

1
Out of stock

12

HOLDER This part replaces 57463-18600.

57465-18601

1
Out of stock

13

COVER

57481-33010

1
Out of stock

14

WASHER,LOCK This part replaces 08321-21038.

09162-03001

2
Out of stock

15

WASHER This part replaces 08322-21038.

08322-01037

2
Out of stock

16

SCREW This part replaces 09125-03105.

09125-03105-XC0

2
Out of stock

17

SWITCH ASSY, HANDLE LH | Includes Item(s) 18 - 27

37400-45603

1
Out of stock

18

KNOB, STOPPER

37414-45602

1
Out of stock

19

SCREW This part replaces 02122-03068.

02122-03067

1
Out of stock

20

KNOB, LIGHTING (OPT)

37411-45012

1
Out of stock

21

KNOB, DIMMER SWITCH

37421-45012

1
Out of stock

22

SCREW This part replaces 02122-03068.

02122-03067

1
Out of stock

23

KNOB, TURN SIGNAL

37513-45011

1
Out of stock

24

BUTTON, HORN

57371-45000

1
Out of stock

25

CONTACT

57372-45000

1
Out of stock

26

SPRING

57382-45000

1
Out of stock

27

SCREW This part replaces 02112-05258.

02112-05257

2
Out of stock

28

BAND (L:120)

09407-12402

2
Out of stock
