1978 Yamaha EX440B Instrument Panel Diagram

← All diagrams

Find the part on the Instrument Panel diagram for your 1978 Yamaha EX440B, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1978 Yamaha EX440B Instrument Panel Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

PANEL, INSTRUMENT

(8G6-77711-00-00)

1
Out of stock

2

BOLT, HEXAGON

97017-06016-00

1

$6.18

In stock

3

WASHER(6TA)

92907-06600-00

1

$0.78

In stock

4

GAUGE, LEVEL

878-21761-00-00

1
Out of stock

5

BOLT (661)

97013-06012-00

1

$4.71

In stock

6

WASHER, PLAIN (646)

92990-06600-00

1

$2.48

In stock

7

ORMNT, INSTR PNL 1

(8G6-77715-00-00)

1
Out of stock

8

LABEL, WARNING 1

8G6-77761-00-00

1
Out of stock

9

INDICATOR 2

8E7-77742-00-00

1
Out of stock

10

INDICATOR 3

878-77743-00-00

1
Out of stock

11

INDICATOR 4

878-77744-00-00

1
Out of stock

12

INDICATOR 5

878-77745-00-00

1
Out of stock

13

LABEL, WARNING 5

(8G6-77765-00-00)

1
Out of stock

14

NUT, NYLON

95707-06300-00

1

$3.20

In stock

15

WASHER, PLATE 8221447500

90201-06057-00

1
Out of stock

16

CABLE, STARTER 1

8L2-26331-00-00

1
Out of stock
