2001 Yamaha ET410TRF 8BY8 Handle Switch Lever Diagram

← All diagrams

Find the part on the Handle Switch Lever diagram for your 2001 Yamaha ET410TRF 8BY8, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2001 Yamaha ET410TRF 8BY8 Handle Switch Lever Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

LEVER HOLDER ASSY (LEFT)

88R-W8291-00-00

1
Out of stock

2

LEVER 1

8H8-83912-00-00

1
Out of stock

3

SCREW, PAN HEAD(41N)

90157-05057-00

—
Out of stock

4

SCREW

8R4-82113-00-00

—
Out of stock

5

NUT, NYLON

95707-05300-00

1
Out of stock

6

. LEVER LOCK ASSEMBLY (8K4-83930-00-00)

82A-83930-00-00

1
Out of stock

7

COLLAR, LEVER

802-83913-00-00

—
Out of stock

8

. SCREW, TAPPING

97707-30712-00

1
Out of stock

9

WASHER, PLAIN LARGE

92907-05200-00

1
Out of stock

10

BEAM SWITCH ASSY

8K4-83950-01-00

—
Out of stock

11

STOP SWITCH ASSY

88R-82530-00-00

1
Out of stock

12

LEVER HOLDER ASSY (RIGHT)

8AU-82720-03-00

1
Out of stock

13

SWITCH, HANDLE 3 (RIGHT)

8AU-83963-00-00

1
Out of stock

14

ENGINE STOP SWITCH ASSY

8AU-82575-09-00

1
Out of stock

15

SCREW, ADJUSTING

8R6-83928-00-00

1
Out of stock

16

THUMB WARMER ASSY

8AU-82970-03-00

—
Out of stock

17

SCREW, TAPPING(88J)

97706-30620-00

—
Out of stock

18

SCREW, PAN TAP.2 SLIT

97707-30630-00

—
Out of stock

19

. CIRCLIP

99001-06400-00

1
Out of stock

20

WASHER, SPECIAL

85G-83663-00-00

—
Out of stock

21

CAP 1

85G-83956-00-00

—
Out of stock

22

SHAFT

88T-8399F-00-00

—
Out of stock
