2008 Kawasaki Er-6n (Australian) Front Hub Diagram

← All diagrams

Find the part on the Front Hub diagram for your 2008 Kawasaki Er-6n (Australian), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2008 Kawasaki Er-6n (Australian) Front Hub Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

601

BEARING-BALL,#6004UUC3

601B6004UU

1
Out of stock

41068

AXLE,FR

41068-0059

1
Out of stock

41073

WHEEL-ASSY,FR,BLACK

41073-0053-R2

1
Out of stock

41073A

WHEEL-ASSY,FR,M.F.P.SILVER

41073-0053-795

1
Out of stock

92049

SEAL-OIL,BJN30427-C3

92049-1057

1
Out of stock

92152

COLLAR,FR HUB,L=115

92152-0087

1
Out of stock

92152A

COLLAR,FR AXLE,L=15.5

92152-0310

1
Out of stock
