1969 Yamaha DS6C (DS6C) Muffler Diagram

← All diagrams

Find the part on the Muffler diagram for your 1969 Yamaha DS6C (DS6C), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1969 Yamaha DS6C (DS6C) Muffler Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

EXHAUST PIPE ASSEMBLY L

(247-14610-30-00)

1
Out of stock

2

EXHAUST PIPE ASSEMBLY R

(247-14620-30-00)

1
Out of stock

3

SILENCER, EXHAUST

(247-14753-30-00)

1
Out of stock

4

PIPE, OUTLET

(178-14752-00-00)

1
Out of stock

5

BOLT(3JP)

97017-06010-00

1

$2.62

In stock

6

WASHER, SPRING

92995-06100-00

1

$2.99

In stock

7

YBS66-6 WASHER, PLAIN

92990-06200-00

1

$0.78

In stock

8

STAY, MUFFLER 2

(247-14781-00-00)

1
Out of stock

9

STAY 5

(247-14782-00-00)

1
Out of stock

10

BOLT(JA9)

90101-08691-00

1

$4.65

In stock

11

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock

12

PROTECTOR, MUFF 1

(247-14718-30-00)

1
Out of stock

13

PROTECTER, MUFF 2

(247-14728-30-00)

1
Out of stock

14

WASHER, PLATE(3MT)

90202-05188-00

1

$6.18

In stock

15

SCREW, BIND(1JK)

98980-06010-00

1
Out of stock

16

WASHER, PLATE(3MB)

90202-05187-00

—

$1.32

In stock

17

SCREW, BIND(2TV)

98980-06008-00

—

$0.58

In stock

18

GASKET, EXHAUST PIPE

3PA-14613-10-00

—
Out of stock

19

NUT(6L2)

95333-08600-00

—

$3.20

In stock

20

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock

21

STAY, MUFFLER 1

(222-14771-30-00)

1
Out of stock

22

BOLT, HEXAGON

97013-08016-00

—

$1.32

In stock

23

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock

24

MUFFLER ASSEMBLY L

(246-14710-00-00)

1
Out of stock

25

MUFFLER ASSEMBLY R

(246-14720-00-00)

1
Out of stock

26

. SILENCER, EXHAUST

171-14753-01-00

1
Out of stock

27

NUT, HEXAGON (663)

95380-05600-00

—

$6.17

In stock

28

YBS67-5 WASHER, SPRING

92990-05100-00

—
Out of stock

29

PIPE, EXHAUST L

(246-14611-00-00)

1
Out of stock

30

PIPE, EXHAUST R

(246-14621-00-00)

1
Out of stock

31

NUT, RING

(246-14612-00-00)

1
Out of stock

32

NUT, MUFFLER JOINT

(137-14713-00-00)

1
Out of stock

33

GASKET, MUFFLER

(137-14714-60-00)

1
Out of stock

34

NUT(6L2)

95333-08600-00

—

$3.20

In stock

35

YBS67-8 WASHER, SPRING

92990-08100-00

1

$4.52

In stock
