2025 Kawasaki Brute Force 450 Suspension/shock Absorber Diagram

← All diagrams

Find the part on the Suspension/shock Absorber diagram for your 2025 Kawasaki Brute Force 450, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki Brute Force 450 Suspension/shock Absorber Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

39007

ARM-SUSP,FR,UPP,RH,P.C.BLACK

39007-Y018-945

1
Out of stock

39007A

ARM-SUSP,FR,LWR,RH,P.C.BLACK

39007-Y019-945

1
Out of stock

39007B

ARM-SUSP,FR,UPP,LH,P.C.BLACK

39007-Y020-945

1
Out of stock

39007C

ARM-SUSP,FR,LWR,LH,P.C.BLACK

39007-Y021-945

1
Out of stock

39186

KNUCKLE,FR,RH

39186-Y009

1
Out of stock

39186A

KNUCKLE,FR,LH

39186-Y011

1
Out of stock

42036

SLEEVE,FR SUSPENSION,UPP

42036-Y005

1
Out of stock

42036A

SLEEVE,FR SUSPENSION,LWR

42036-Y007

1
Out of stock

45014

SHOCKABSORBER,FR,P.C.BLACK

45014-Y012-945

1
Out of stock

49091

WASHER-SEAL,SUSPENSION

49091-Y001

1
Out of stock

59266

JOINT-BALL

59266-Y005

1
Out of stock

92033

RING-SNAP,29MM

92033-Y057

1
Out of stock

92033A

RING-SNAP,55MM

92033-Y060

1
Out of stock

92043

PIN,3X25

92043-Y009

1
Out of stock

92092

BUSHING-RUBBER,FR SUSPENSION

92092-Y010

1
Out of stock

92147

BEARING,WHEEL

92147-Y004

1
Out of stock

92154

BOLT,FLANGE,10X40

92154-Y149

1
Out of stock

92154A

BOLT,FLANGE,10X85

92154-Y254

1
Out of stock

92172

SCREW,10X180

92172-Y107

1
Out of stock

92200

WASHER,SPRING

92200-Y095

1
Out of stock

92210

NUT,10MM

92210-Y009

1
Out of stock

92210A

NUT,12MM

92210-Y097

1
Out of stock
