Kawasaki Brute Force 450 Front Hub Diagram

#

Description
Price

11065

CAP,WHEEL

11065-Y051

$4.55

16126

VALVE,RIM

16126-Y001

$5.69

39184

BRACKET-ASSY,CALIPER,FR,RH

39184-Y003

$78.29

39184A

BRACKET-ASSY,CALIPER,FR,LH

39184-Y004

$78.29

41009

TIRE,FR,AT24X8-12

41009-Y011

$275.78

41036

HUB-ASSY,FR

41036-Y007

$98.04

41080

DISC,FR

41080-Y010

$50.78

43041

CALIPER-ASSY,FR,RH,SILVER

43041-Y016-934

$244.07

43041A

CALIPER-ASSY,FR,LH,SILVER

43041-Y017-934

$244.07

43048

PISTON-CALIPER

43048-Y006

$57.42

43049

PACKING

43049-0557

$7.59

43056

BREATHER-BRAKE

43056-0010

$3.64

43056A

BREATHER-BRAKE

43056-Y005

$23.32

43057

CAP-BREATHER

43057-Y001

$1.63

43082

PAD-ASSY-BRAKE,FR

43082-Y014

$78.87

49006

BOOT,CALIPER

49006-Y010

$3.29

49058

WHEEL,FR

49058-Y007

$316.81

92043

PIN,COTTER,3X40

92043-Y055

$3.71

92154

BOLT,FLANGE,8X20

92154-Y053

$4.47

92154A

BOLT,SHOULDER

92154-Y237

$7.44

92210

NUT,10MM

92210-Y107

$7.44

92210A

NUT,CASTLE,22MM

92210-Y112

$21.44
