1968 Yamaha YCS1C (YCS1C) Clutch Diagram

← All diagrams

Find the part on the Clutch diagram for your 1968 Yamaha YCS1C (YCS1C), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1968 Yamaha YCS1C (YCS1C) Clutch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GEAR, KICK PINION

174-15631-01-00

1
Out of stock

1

PRI DRVN GEAR

(174-16105-01-00)

1
Out of stock

1

PRI DRVN GEAR

(174-16105-01-00)

1
Out of stock

1

CLUTCH ASSEMBLY

(174-16301-02-00)

1
Out of stock

1

. BOSS, CLUTCH

174-16371-01-00

1
Out of stock

1

ROD, PUSH 2

237-16357-01-00

1
Out of stock

1

SCREW, SPECL SHAPE

(90149-05147-00)

1
Out of stock

2

CLUTCH ASSEMBLY

(174-16301-02-00)

1
Out of stock

2

O-RING (173)

93210-85075-00

1

$4.52

In stock

3

CLUTCH ASSEMBLY

(174-16301-02-00)

1
Out of stock

3

. BOSS, CLUTCH

174-16371-01-00

1
Out of stock

4

PLATE, CLUTCH 1

336-16324-10-00

1

$17.51

In stock

5

RING, CUSHION

137-16367-00-00

1

$14.80

In stock

6

PLATE, FRICTION

3HA-16321-00-00

1

$26.75

In stock

7

PLATE, PRESSURE

132-16351-00-00

1

$50.51

In stock

8

SPRING (137-16333-00)

90501-20122-00

—
Out of stock

9

SCREW, SPECL SHAPE

(90149-05147-00)

1
Out of stock

10

COLLAR (174-16181-00)

90387-20439-00

1
Out of stock

11

GEAR, KICK PINION

(174-15631-00-00)

1
Out of stock

12

PLATE, THRUST 2

174-16164-00-00

1
Out of stock

13

BALL

93505-16006-00

—

$2.22

In stock

14

ROD, PUSH 2

237-16357-01-00

1
Out of stock

15

CROWN, PUSH

(174-16348-00-00)

1
Out of stock

16

LEVER, PUSH 2

(174-16362-00-00)

1
Out of stock

17

BOLT SET 241163430000

90113-06013-00

—
Out of stock

18

NUT(650)

95380-06700-00

—

$6.17

In stock

19

SPRING, COMPRESSION

(90501-08037-00)

1
Out of stock

20

SCREW, PAN HEAD(6A3)

97885-06008-00

1

$1.07

In stock

21

WASHER, PLATE

(90201-06054-00)

1
Out of stock

22

CLUTCH ASSEMBLY

(174-16301-02-00)

1
Out of stock

23

SCREW, PAN

98507-06014-00

—

$6.18

In stock

24

SPRING, COMPRESSION

(90501-08040-00)

1
Out of stock

25

. BEARING, FLAT #41

93341-22603-00

1
Out of stock

26

. PLATE, THRUST 1

174-16154-00-00

1
Out of stock

27

WASHER, LOCK (1L8)

90215-16127-00

—

$8.91

In stock

28

NUT,SPEC'L SHAPE

90179-16018-00

—

$11.26

In stock

29

ROD, PUSH

174-16356-00-00

—
Out of stock
