2004 Yamaha V Star Custom CA (XVS65SC) Taillight Diagram

← All diagrams

Find the part on the Taillight diagram for your 2004 Yamaha V Star Custom CA (XVS65SC), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2004 Yamaha V Star Custom CA (XVS65SC) Taillight Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

TAILLIGHT ASSY

4TV-84700-00-00

—
Out of stock

2

BULB, TAIL LAMP (12V 32/3CP)

256-84714-61-00

1
Out of stock

3

GASKET, TAIL LENS

4TX-84723-00-00

1
Out of stock

4

LENS, TAILLIGHT

4TR-84733-00-00

1
Out of stock

5

SCREW, PAN TAP.2

97707-40520-00

1
Out of stock

6

WASHER, PLATE

90201-06380-00

1
Out of stock

7

NUT, SELF-LOCKING

95617-06100-00

1
Out of stock

8

BRACKET, LICENSE

5FB-84751-00-00

—
Out of stock

9

DAMPER 2

51Y-21639-00-00

1
Out of stock

10

BOLT, FLANGE(4DU)

95027-06014-00

1
Out of stock

11

NUT, SELF-LOCKING

95617-06100-00

1
Out of stock

12

REFLECTOR, REAR 1

449-85131-02-00

1
Out of stock

13

REAR REFLECTOR ASSY

3Y6-85130-02-00

1
Out of stock

14

NUT, FLANGE(3GM)

95707-05500-00

1
Out of stock

15

CORD, TAILLIGHT

5KP-84717-10-00

1
Out of stock

16

BRACKET, FENDER

5FB-21617-00-00

—
Out of stock
