1981 Yamaha XT250H Intake 2 Diagram

← All diagrams

Find the part on the Intake 2 diagram for your 1981 Yamaha XT250H, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1981 Yamaha XT250H Intake 2 Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

THROTTLE BODY ASSY

5XT-13750-13-00

—

$791.99

In stock

2

PIPE INLET ASSEMBLY

5XT-13930-11-00

1

$282.23

In stock

3

O-RING

5CA-14147-00-00

1

$8.70

In stock

4

BRACKET, THROTTLE

5XT-14571-00-00

—

$24.15

In stock

5

SCREW, PAN HEAD(3LA)

98517-05010-00

1

$3.52

In stock

6

SCREW, AIR ADJUSTING

1S4-14123-00-00

—

$11.12

In stock

7

O-RING

1S4-14147-00-00

1
Out of stock
