Find the part on the Electrical 3 diagram for your 1993 Yamaha Vmax-4 (VX750T), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1993 Yamaha Vmax-4 (VX750T) Electrical 3 Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

REFLECTOR ASSEMBLY

81E-85110-00-00

1
Out of stock

2

BASE, REFLECTOR

82M-85115-00-00

1
Out of stock

3

BASE, REFLECTOR

82M-85115-50-00

1
Out of stock

4

WASHER, PLAIN (646)

92990-05600-00

1
Out of stock

5

NUT, NYLON

95707-05300-00

1

$2.74

In stock

6

REAR REFLECTOR ASSY

3Y6-85130-02-00

1

$22.72

In stock

7

NUT, FLANGE(3GM)

95707-05500-00

1

$6.18

In stock
