Find the part on the Fuel Cock diagram for your 2009 Suzuki VS800, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2009 Suzuki VS800 Fuel Cock Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

COCK ASSY,FUEL | Includes Item(s) 2 - 3 This part replaces 44300-38A72.

44300-38A73

1
Out of stock

2

LEVER

44306-38A00

1
Out of stock

3

SCREW, LEVER

44307-38A00

1
Out of stock

4

BOLT

09128-06057

2
Out of stock

5

GASKET

09168-06026

2
Out of stock

6

HOSE FUEL PUMP | MODEL K6/K7 This part replaces 44320-38A02.

44320-38AR0

1
Out of stock

6

HOSE, FUEL | MODEL K8/K9

44320-38AA0

1
Out of stock

7

TUBE, FUEL HOSE

44311-38A01

1
Out of stock

8

CLIP, FUEL HOSE

09401-11415

2
Out of stock
