1984 Yamaha V-MAX (VMX540H) Bumper Diagram
Find the part on the Bumper diagram for your 1984 Yamaha V-MAX (VMX540H), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.
#
1
FRONT BUMPER
8M6-77510-00-00
3
YBS67-5 WASHER, SPRING
92990-05100-00
7
YBS67-5 WASHER, SPRING
92990-05100-00
8
WASHER, PLAIN (646)
92990-05600-00
9
BUMPER, FRONT 2
8M6-77512-00-00
10
BUMPER, FRONT 1
8M6-77511-00-00
11
BUMPER, FRONT 3
8M6-77513-00-00
12
BUMPER, FRONT 4
8M6-77514-00-00
13
SPACER, BUMPER
8M6-77529-00-00
17
END, BUMPER
8M6-77523-00-00
18
END, BUMPER
8M6-77524-00-00
20
FLAP
8V9-77595-00-00
22
BUMPER, REAR 1
8M6-77541-00-00
23
WASHER 1
8M6-77525-01-00
24
WASHER 2
8M6-77526-01-00
33
BUMPER, REAR 2
8M6-77542-00-00
37
BUMPER, REAR 3
8M6-77543-00-00
38
BUMPER, REAR 4
8M6-77544-00-00
39
SCREW, BINDING
98907-05012-00
45
PROTECTOR 1 (8M6-77551-00)
8M6-77551-01-00
46
PROTECTOR 2
8M6-77552-00-00
47
RIVET (8M6)
90269-04025-00
49
PROTECTOR 3
8M6-77553-00-00
50
PROTECTOR 4
8M6-77554-00-00
51
EMBLEM 14
8M6-77369-00-00
52
PROTECTOR 6
8R9-77556-00-00
53
PROTECTOR 7
8M6-77557-00-00
54
STAY 1
8M6-77535-00-00
56
WASHER, PLATE (8M6)
90201-047A2-00
60
PATCH 7
8M6-21967-00-00
