2020 Kawasaki Versys-X 300 ABS Footrests Diagram

← All diagrams

Find the part on the Footrests diagram for your 2020 Kawasaki Versys-X 300 ABS, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2020 Kawasaki Versys-X 300 ABS Footrests Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13042

WEIGHT,STEP

13042-0759

1
Out of stock

34028

STEP,RR,LH

34028-0334

1
Out of stock

34028A

STEP,RR,RH

34028-0335

1
Out of stock

34028B

STEP,RUBBER

34028-0349

1
Out of stock

34028C

STEP,FR,LH

34028-0350

1
Out of stock

34028D

STEP,FR,RH

34028-0351

1
Out of stock

482

CIRCLIP-TYPE-E,10MM

482EA0100

1
Out of stock

482A

CIRCLIP-TYPE-E

482EA5000

1
Out of stock

92001

BOLT,BANK SENSOR

92001-1905

1
Out of stock

92022

WASHER,5.2X13X1

92022-1380

1
Out of stock

92043

PIN,5X31.8

92043-0907

1
Out of stock

92043A

PIN,12X39

92043-0924

1
Out of stock

92081

SPRING,STEP,RR

92081-1612

1
Out of stock

92145

SPRING,STEP RETURN

92145-0723

1
Out of stock

92150

BOLT,SOCKET,5X25

92150-1684

1
Out of stock

92152

COLLAR,STEP

92152-0658

1
Out of stock

92152A

COLLAR,5.6X8X10.5

92152-1545

1
Out of stock

92161

DAMPER,8X16X10

92161-1935

1
Out of stock

92200

WASHER

92200-1892

1
Out of stock
