1985 Yamaha Trial (TY350N) Starter Diagram

← All diagrams

Find the part on the Starter diagram for your 1985 Yamaha Trial (TY350N), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1985 Yamaha Trial (TY350N) Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GEAR, KICK

38V-15641-01-00

1
Out of stock

1

KICK AXLE ASSEMBLY

38V-15660-00-00

1
Out of stock

3

CLIP 315156870000

90468-26048-00

1
Out of stock

4

WASHER, PLATE

90201-20358-00

1
Out of stock

5

UNAVAILABLE IN PRICE BOOK

90508-20632-00

1
Out of stock

6

GUIDE, SPRING

(38V-15664-00-00)

1
Out of stock

7

GEAR, KICK IDLE (23T)

38V-15651-00-00

1
Out of stock

8

WASHER, PLATE (525)

90201-17545-00

1

$6.68

In stock

9

CIRCLIP(1EY)

99009-17400-00

1
Out of stock

10

OIL SEAL,SD-TYPE

93102-20309-00

1

$8.77

In stock

11

KICK CRANK ASSEMBLY

53Y-15620-00-00

1
Out of stock

12

BOSS, KICK CRANK

(53Y-15621-00-00)

1
Out of stock

13

BALL

93501-04011-00

1
Out of stock

14

SPRING, COMPRESSION (23X)

90501-13720-00

1

$6.68

In stock

15

O-RING(M01)

93210-19758-00

1

$5.53

In stock

16

SCREW, COUNTERSUNK (5Y1)

90152-06010-00

—
Out of stock

17

NUT(1EE)

90179-12659-00

—

$5.37

In stock

18

CIRCLIP (525)

93410-17037-00

—

$6.68

In stock
